MM5314, 5314
Alarm Clock Chip
If it resets close to 12:00 (or 00:00), concider there may be some random
high frequency noise entering into the 50/60 Hz input on startup, causing
it to rapidly advance from 12:00.(Is this after you plug it in?) Try
bypassing the 50/60Hz input with a simple RC filter. Contributed by Paul
Grohe.
[1] Hold (check to see if this pin is stuck on power-up)
[2] MUX timing RC network (~100k to Vdd, 0.005uF to Vss)
